for some reason my brain only became aware of the existence of this circuit around the beginning of february this year.
i do recall catching a glimpse of the reissue version a while ago - the maxon ST9pro+ , on a rig rundown video, but i had no idea what i was looking at and kinda forgot all about it.
then i saw a video in february this year with someone showing off the maxon ST-01 (early 80s build), and comparing it to the reissue ST9pro+ (which also looks quite nifty tbh, has a toggle for classic mode / low boost mode+different clippers, and an internally switchable chargepump for 18v mode)
and boy howdy hearing that action with the ‘mid boost’ control had me very intrigued.
it’s supposedly a fixed ~8dB boost stage that sweeps from 200 - 2K Hz.
super cool. i can’t believe i didn’t know about this years ago.
i would describe the mid boost control like this:
- set it around 9o’clock and it kinda sorta sounds like a regular TS9/808 (can’t really take away the effect of that extra boost/gain stage)
- turn it all the way down and that’ll remove the classic mid hump.
- set to 12 o’clock and it starts to get quite bitey ..and yeah i’m sure you can imagine the sort of response you get as you move further up the freq spectrum…
to my ears, anything past 1oclock isn’t nice (….but i guess it’s subjective and depends on what amp / rig it’s setup with)
anyway, i was like holy crap i have to build this asap.
but there was a bit of a hold up, because looking at that super cool 80s styling of the maxon ST-01
... it had me real inspired to have a go at possibly doing a basic design for a uv print at tayda (like all the incredible and beautiful builds here weren’t already inspiring enough..
)
i read and read through all the threads, all the comments about what it takes to put together a properly formatted pdf for tayda uv printing. CMYK. vector only. white/ color/gloss layers. roland swatches. etc.
i spent ages reading about all of this and getting myself prepared and figuring out how i could do it with my 2012 mac mini running high sierra os (lmao). i really thought i could do this
i decided to go with inkscape and scribus (supposedly folks have done this successfully).
download both the programs. got inkscape running. downloaded the drilling template pdf for 125B etc etc.
spent about an hour or so with inkscape before i nearly lost my mind, took ten deep breaths, shut down my computer and walked away.
i tried guys, i really tried.
so i had a sook for a while, and then just went ahead and ordered a green 125B, some nifty green+black knobs, and a 10mm LED + bezel, because why not have a stupidly large LED.
also had a small lightbulb moment - did a search on redbubble and ordered some ‘black grid’ vinyl stickers that i thought might make a nice backing/'faceplate' for some dymo labels to sit on top of.
meanwhile, i built the circuit, following this layout, and had it running. wonderful. (filmed the build of it too, as seen on this thread)
sounds great. quite a huge/hot output.
had a few issues with it, but i guess that’s how it goes.
pretty happy with the black grid vinyl effect and those green knobs. i wanted 80s and i think i got there.
i’ll do a demo soon.
