These are the first boards I have designed and had made. I used EasyEda and JLC.
What’s on *YOUR* workbench?
- Thread starter Bricksnbeatles
- Start date
These are the first boards I have designed and had made. I used EasyEda and JLC.
jimilee
Well-known member
Man, I love that faceplate. Are you going to mod the circuit or go stock. I built one stick and was thinking about a second one modded.
Fingolfen
Well-known member
First one is going to be stock, but then I'm likely going to do a Robinette mod
Harry Klippton
Not Interested
Reviving this abused XLii
giovanni
Well-known member
Finally boxing my Dream Fuzz. I have a work in progress faceplate so maybe this will come together in the next couple weeks. Fingers crossed I have no issues.
Edit: I got access to a drill press today and drilled pilot holes for a few upcoming builds. The drill press makes this process soooooo much easier and like 200% more accurate than a hand drill.
Edit: I got access to a drill press today and drilled pilot holes for a few upcoming builds. The drill press makes this process soooooo much easier and like 200% more accurate than a hand drill.
Hal Harvey
Well-known member
Changed out the stock fan on my recently acquired Boogie Mark V 35 with one that is practically silent. I had to triple check the fan was actually on haha. Better air flow specs too - sometimes you CAN have your cake and eat it too
Now back to pedals…
Now back to pedals…
jessenator
Well-known member
Digging into the FX69
Friends of mine love it and hate it. I haven't made up my mind yet. It's like, you've got three duals in there, some OD/TS/D topology lite, plus a Si fuzz(?)… it's mad.
I do like its tone control, though. Very nice.
Friends of mine love it and hate it. I haven't made up my mind yet. It's like, you've got three duals in there, some OD/TS/D topology lite, plus a Si fuzz(?)… it's mad.
I do like its tone control, though. Very nice.
JTEX
Well-known member
Prototyping a sort of "shield", à la Arduino, for my Rock Engine. Will go onboard my guitar, replacing its retired predecessor Shockman. The little toggles turn on/off the distortion, chorus and delay. The 3 green pots are the delay controls. Blue pot is the headphones volume. Jacks are for the phones and aux in.
05/30 Update: the shield worked great on the 1st try! Maybe I'll make it into a proper PCB. Or maybe not. Almost nobody wants onboard stuff. Belt packs anyone? Altoid tins? Anything that's not a pedal?
Oops, wrong site?
05/30 Update: the shield worked great on the 1st try! Maybe I'll make it into a proper PCB. Or maybe not. Almost nobody wants onboard stuff. Belt packs anyone? Altoid tins? Anything that's not a pedal?
Oops, wrong site?
Last edited:
jessenator
Well-known member
Turns out breadboarding whilst sleep-deprived leads to errors.
Rebuilt it with a fresh head and after navigating some touching component leads got the actual intended sound.
I kinda like it.
Swapping out the 100k distortion pot with 500k gives me more control (don't have a 250k for some reason…) so I'll keep that option open
Robert
Reverse Engineer
bean
Legume Liaison
Haha. Yeah I've had the same Office Max desk for 15 years. It got so trashed I bought peel and stick vinyl tiles to cover it. Really durable.
Mentaltossflycoon
Well-known member
Nostradoomus
Well-known member
One knob version of the umbrella mayonnaise/kewpie fuzz (I always called it creepy baby mayo
). Probably my finest layout so far. Had an issue with voltages all across the board til I checked my schematic and had a 100k resistor instead of 1k on the power rail
. All good now, it sounds great.
blackhatboojum
Well-known member
In the biz we call those, “apprentice marks”.
After a month away and what seems like a month sorting components, getting back to the iron feels good.
Replaced bad jack in my SRX505 and fitting some new matching knobs (I added one when I installed the dark glass tone capsule a while back -- highly recommend!)
They're solid black aluminums from Ali. I filled in the dimple with chrome marker.
Replaced bad jack in my SRX505 and fitting some new matching knobs (I added one when I installed the dark glass tone capsule a while back -- highly recommend!)
They're solid black aluminums from Ali. I filled in the dimple with chrome marker.
