Missing Build Docs / Schematics

[Iceman53]

Yes, I drew up a through-hole version as well.

You technically could do it with the Buffer/Inverter PCB in the meantime.

Signal Buffer / Inverter - PedalPCB.com

Signal Buffer / Inverter

www.pedalpcb.com

Great!

Do you have a schematic for the buffer/inverter by chance? Save me from tracing it out to see what's 'going on' in the circuit



[Iceman53]

Great!

Do you have a schematic for the buffer/inverter by chance? Save me from tracing it out to see what's 'going on' in the circuit

Never mind. I found that schematic in another post from you. Thank you!



[Feral Feline]

Since the Signal Buffer inverter was just mentioned, and somebody stumbling onto this page of the thread first before finding the referenced schematic would still need to look for it ... here 'tis:

SIGNAL BUFFER / INVERTER SCHEMATIC (PNG)

Posted in this thread here: #1598



[rkooser]

It fits a 1590BB2, the slightly deeper 1590BB.


Yes, of course. I've been away from my bench for a few days so I have some catching up to do, but I'll get it posted for you.

All - is there build documentation floating around anywhere for the acrobat yet?



[DGWVI]

All - is there build documentation floating around anywhere for the acrobat yet?

Been waiting on this, too



[fgb1967]

Hey,
sorry to bug you, but hoping that docs for following will be available soon :
Silica Fuzz,
410 Fuzz,
Cast Iron Fuzz,
Fudge Round Fuzz.
Thanks!



[ctelecaster]

Mentioned it in the thread but figured I'd mention it here too - would really love to get the build doc/schematic for the Ginsly's Acoustic Preamp (K&K Pure Sound) you just put up this past weekend!



[GordyLee]

Last December (2024) I purchased the Salesman Overdrive PCB and also posted a request for the Build Doc - it's now a year later and still nothing... Any chance of this one getting posted sometime in the near future? Thanks.



[nshane]

I got an ADHD Overdrive for Christmas and before I had a chance to download the build doc it went away. Anyone have one or do I need to wait for the updated doc?



[JackOnFire]

Been waiting on this, too

Another friendly request for the Acrobat build doc, would be much appreciated. Thank you!



[jimilee]

Another friendly request for the Acrobat build doc, would be much appreciated. Thank you!

@Robert



[darwin999]

I got an ADHD Overdrive for Christmas and before I had a chance to download the build doc it went away. Anyone have one or do I need to wait for the updated doc?

I think it's here:

Post in thread 'OCD/ADHD Toans'

Apr 28, 2023

Here's the schematic and build doc for the V2 of the ADHD Drive . . .

• Cybercow



[jcpst]

and v3 is in the post after that

https://docs.pedalpcb.com/project/Schematic-ADHD.pdf



[zeropluszero]

For the Two Tone Fuzz, how far down from the bias and impedance are the two switches? (I'm looking for the measurement so I can get Tayda to drill it, but the PCB is still in the mail at the moment) I have the rest of the drill template set, appear to be a standard 4knob otherwise



[Fama]

For the Two Tone Fuzz, how far down from the bias and impedance are the two switches? (I'm looking for the measurement so I can get Tayda to drill it, but the PCB is still in the mail at the moment) I have the rest of the drill template set, appear to be a standard 4knob otherwise

This worked fine for me https://drill.taydakits.com/box-designs/new?public_key=d0RidDhadTVnemZrRVBvaEFMOVA4dz09Cg==

It's for an outie DC jack so change it to what suits you, or just copy the switch locations.

Edit: I guess for posterity the Y positions are 38mm, 12.8mm and -8.3mm, so that's the two pots and a switch that are in line vertically. So... 21.1mm? I don't remember how I ended up with that, but like I said, it worked.
